24 Inch Waterproof Industrial Panel PC

Contact us to check freight cost
  • No-Risk Money Back Guarantee!
  • No Hassle Refunds
  • Secure Payments
  • Fast Delivery
  • Techinical support

24 Inch Waterproof Industrial Panel PC

Industrial Panel Pcs are industrial control computers exclusively used by the industry. Their basic performance and compatibility are almost the same as those of commercial computers, but industrial tablet PCs pay more attention to safety and stability in different environments. It provides the best solution for man-machine interface and production process control.

24 inch color TFT industrial display, 1920×1080 resolution, adopts ten-point capacitive touch with high touch sensitivity, aluminum-enhanced structural shell, and high cost performance. High brightness Sunlight readable(optional), Sealed IP65 and IP66(optional), Embedded Mounting and VESA 75/100. Dimensions are detailed in the product sample drawings.

Product Parameter of 24 Inch Industrial Panel PC

System CPU Intel Baytrail Celeron Quad Core J1900 2.0GHz Processor
BIOS Award BIOS 4/8Mbit SPI Flash ROM
Chipset Intel Baytrail SOC CPU Integrated
Memory 1 x SO-DIMM, DDR3 1333MHz Memory, 2GB, Max.8GB
Graphic Chipset CPU integrated graphics HD and support 1080p
Storage 64GB SSD or 500GB HDD
I/O Serial Ports 1x COM (Optional)
USB Ports 1 x USB 2.0(Waterproof Connector and Cable)
Power Port 1 x 12V DC Jack(Waterproof Connector and Cable)
LAN 1 x 10/100/1000Mbps Ethernet(Waterproof Connector and Cable)
WIFI Built-in, 802.11a/b/g/h (optional)
Touch Screen Type Projected Capacitive Touch Screen with 10 independent touch points
Response Time ≤5ms
Interface USB or COM, default to USB
Transparency ≥85%
Lifetime ≥50,000,000 times/click
OS Support Windows CE/XP/7/8/10, Linux, Mac, Android
General Power Input DC 12V
Power Switch Optional
Mounting Option 75 x 75/100 x 100mm VESA Mount
Operation/Power Saving TBA
Operating Temperature -10~60℃
Storage Temperature -20~70℃
Operation Humidity 10%~90%(No Condensation)
OS Support Windows 7/ Windows XP/ Windows 8/ Linux
Mounting Method VESA, embedded/panel mounting with clamps, desktop stand
Order Information Stainless Steel Full IP65/IP66 Panel PC J1900 with Tempered Glass: ITD**PPCG1IPSJ1
Stainless Steel Full IP65/IP66 Panel PC J1900 with Resistive Touch: ITD**PPCT1IPSJ1
Stainless Steel Full IP65/IP66 Panel PC J1900 with PCAP Touch: ITD**PPCT5IPSJ1
Stainless Steel Full IP67 Panel PC J1900 with Tempered Glass: ITD**PPCG1IPSJ2
Stainless Steel Full IP67 Panel PC J1900 with Resistive Touch: ITD**PPCT1IPSJ2
Stainless Steel Full IP67 Panel PC J1900 with PCAP Touch: ITD**PPCT5IPSJ2
Aluminum Alloy Full IP65/IP66 Panel PC J1900 with Tempered Glass: ITD**PPCG1IPAJ1
Aluminum Alloy Full IP65/IP66 Panel PC J1900 with Resistive Touch: ITD**PPCT1IPAJ1
Aluminum Alloy Full IP65/IP66 Panel PC J1900 with PCAP Touch: ITD**PPCT5IPAJ1
Steel Full IP65/IP66 Panel PC J1900 with Tempered Glass: ITD**PPCG1IPXJ1
Steel Full IP65/IP66 Panel PC J1900 with Resistive Touch: ITD**PPCT1IPXJ1
Steel Full IP65/IP66 Panel PC J1900 with PCAP Touch: ITD**PPCT5IPXJ1
