Wireless Video LCD Monitor Screen

Contact us to check freight cost

panel type: 12.1″ TFT color LCD
active display area: 249.0(H)mmx187.5(V)mm
resolution: 800×600
contrast ratio: 500:1
transmitter: 1.2G/2.4G/5.8G
power input: DC12V or AC 100~240V

  • No-Risk Money Back Guarantee!
  • No Hassle Refunds
  • Secure Payments
  • Fast Delivery
  • Techinical support

12.1″ 2.4G Wireless Video LCD Monitor Screen



2.4G Hz Wireless Video Technology support one receiver to connect 4 transmitters. Day and night monitoring with clear images for 24 hours. Half-duplex voice transmission, voice clear, volume of sound(0~10) is adjustable.

Datasheet of 12.1″ 2.4G Wireless Video LCD Monitor Screen:

Model NO. LMW121T
LCD Panel 12.1″ TFT Color LCD
Active Display Area 249.0(H)mmx187.5(V)mm
Resolution 800X600
Brightness 600cd/㎡
Contrast Ratio 500:1 (typ.)
Response Time 12ms
Backlight LED
Dimming range 10~100%
Viewing Angle -70~70 / -65~55 (H/V)
Transmitter 1.2G / 2.4G / 5.8G
Input Signal PC Connector: D-sub-15pin VGA Input
VIDEO NTSC/PAL Composite Video
2ch BNC In (Lever:1.0V p-p/75ohm)
Optional S-Video, DVI, HDMI, USB
Power Input DC12V/ AC100-240V
Operating Method 5 keys keypad OSD and Remote
Power Consumption Max.25W
Operation Temperature 0℃~60℃
Operation Humidity 10%~80%
Storage Temperature -20℃~65℃
Storage Humidity 5%~85%
Case Material Metal
Net Weight 2.8kg
